Beryllium Copper and Its Characteristics Overview

Beryllium copper, also known as beryllium bronze, is a copper alloy with beryllium as the main alloying element. It possesses a series of excellent physical and chemical properties such as high strength, high elasticity, high hardness, fatigue resistance, and corrosion resistance. These characteristics make beryllium copper widely applicable in various fields.

Here are some common alloy material numbers of beryllium copper:

C17200 Beryllium Copper

This alloy is also known as Beryllium Copper 25, which is composed of copper and 1.8-2.0% of beryllium. It possesses excellent corrosion resistance and high strength, and thus can be widely applied in fields such as aerospace and manufacturing.

C17000 Beryllium Copper

This alloy is also known as Beryllium Copper 174. It is mainly composed of copper and approximately 1.7% of beryllium, along with a small amount of nickel and silicon. It has excellent electrical conductivity and corrosion resistance, and thus can be used in electronic devices and battery applications for electrical appliances.

C17510 Beryllium Copper

This copper alloy is also known as Beryllium Copper 3. It is composed of copper, 1.8-2.0% of beryllium, and a small amount of nickel and silicon. It has excellent wear resistance and durability, and is commonly used for manufacturing molds and templates, etc.

C17500 Beryllium Copper

This alloy is also known as Beryllium Copper 10. It is composed of copper, 1.9-2.2% of beryllium, and a small amount of nickel. It has excellent thermal conductivity, mechanical properties, and corrosion resistance, and is typically used to manufacture heat exchangers, construction machinery, and seawater disinfection equipment, among others.

Additionally, some common copper alloys also contain a small amount of beryllium. These alloys are usually denoted by the code "BeCu" for their material designation. For instance, hard brass (Phosphor Bronze) and aluminum bronze (Aluminum Bronze), which are commonly used in the manufacturing of electronic devices, all contain a small amount of beryllium.

Main application fields of beryllium copper

1. Mold manufacturing

Beryllium copper has extensive applications in mold manufacturing. Its high strength, high hardness, wear resistance and corrosion resistance make it an ideal material for manufacturing various molds, especially high-precision molds such as injection molds and die-casting molds. Beryllium copper can significantly increase the service life and manufacturing accuracy of the molds.

2. Electronics industry

In the electronics industry, beryllium copper is widely used due to its high electrical conductivity and thermal conductivity. It can be used as the electrode material for resistance welding, as well as various switch parts and current-carrying elements. Moreover, in the manufacturing of mobile phones, batteries and other electronic products, beryllium copper also plays an important role.

3. Marine engineering

Due to its excellent resistance to seawater corrosion, beryllium copper has extensive applications in marine engineering. For example, in the construction body of submarine cable repeaters, beryllium copper is an indispensable material. It can maintain corrosion resistance for over 40 years in seawater, ensuring the stable operation of submarine cables.

4. Other fields

In addition to the above fields, beryllium copper is also widely used in the manufacturing of explosion-proof tools, bearings, bearing shells, shaft sleeves, gears, etc.耐磨件。 At the same time， its good conductivity， cold resistance and non-magnetism also make beryllium copper an ideal material for manufacturing various advanced elastic components， such as diaphragms， membranes， and bellows.

Beryllium copper, as a high-performance copper alloy material, plays a significant role in various fields. Its excellent physical and chemical properties make it an ideal choice for mold manufacturing, electronics industry, marine engineering, and other areas. With the continuous development of technology, the application scope of beryllium copper will further expand.
